Simple Mail Transfer Protocol (SMTP)

Email delivery over the Internet requires the following components:

Mail Submission Agent (MSA)
Mail Transfer Agent (MTA)
Mail Delivery Agent (MDA)
Mail User Agent (MUA)

SMTP Diagram

Simple Mail Transfer Protocol (SMTP) is used to communicate with an MTA server. Because SMTP uses cleartext, where all commands are sent without encryption, we can use a basic Telnet client to connect to an SMTP server and act as an email client (MUA) sending a message.

SMTP server listens on port 25 by default. However, it can also run on TCP port 465 and 587.

Send an email using Telnet

# Connect using telnet
telnet MACHIE_IP 25

# Issue a HELO message:
HELO attacker.xyz

# Indicate the sender:
mail from:admin@attacker.xyz
# Indicate the recipient:
rcpt to:root@openmailbox.xyz
data
Subject: Hi
Hello,
This is a fake email.
.
# Issue <CR><LF>.<CR><LF> (or Enter . Enter to put it in simpler terms)

Send an email using sendemail command

sendemail -f admin@attacker.xyz -t root@attacker.xyz -s TARGET_HOST -u Fakemail -m "Hi, this is a fake email" -o tls=no

Enumeration

Metasploit Auxiliary Modules

auxiliary/scanner/smtp/smtp_version

use auxiliary/scanner/smtp/smtp_version

set RHOSTS TARGET_IP

run

auxiliary/scanner/smtp/smtp_enum

It performs user enumeration.

use auxiliary/scanner/smtp/smtp_enum

set RHOSTS TARGET_IP

set USER_FILE USERS_WORDLIST
# Example: /usr/share/metasploit-framework/data/wordlist/unix_users.txt

run

Netcat

nc TARGET_IP PORT

# Verify if a user exists
VRFY user@domain

smtp-user-enum

smtp-user-enum -U WORDLIST -t TARGET_IP
